BBO nonlinear crystal As one of the most important nonlinear optical crystals, beta-barium borate (β-BaB2O4，β-BBO) combines many outstanding features such as its high nonlinear optical coefficients, low group-velocity dispersion, broad transparency range (189–3500 nm) and high damage threshold. This unique combination ensures β-BBO crystal a promising candidate for a wide range of nonlinear optical applications such as frequency converters and optical parametric oscillators. In the realm of quantum optics, β-BBO crystal can be used to generate entangled photon pairs and ten-photon entanglement. β-BBO Nonlinear Crystal—a widely used nonlinear crystal for frequency conversion in the ultraviolet, visible and near-infrared BBO is a negative uniaxial crystal, which provides phase matching for various second-order interactions almost over its entire transparency range (from 185 nm to 3.3 µm, as deduced from the transmittance measurements using crystal samples of several mm thickness), making

BBO nonlinear crystal As one of the most important nonlinear optical crystals, beta-barium borate (β-BaB2O4，β-BBO) combines many outstanding features such as its high nonlinear optical coefficients, low group-velocity dispersion, broad transparency range (189–3500 nm) and high damage threshold. This unique combination ensures β-BBO crystal a promising candidate for a wide range of nonlinear optical applications such as frequency converters and optical parametric oscillators. In the realm of quantum optics, β-BBO crystal can be used to generate entangled photon pairs and ten-photon entanglement. β-BBO Nonlinear Crystal—a widely used nonlinear crystal for frequency conversion in the ultraviolet, visible and near-infrared BBO is a negative uniaxial crystal, which provides phase matching for various second-order interactions almost over its entire transparency range (from 185 nm to 3.3 µm, as deduced from the transmittance measurements using crystal samples of several mm thickness), making

Co:spinel Q-Switch crystal Cobalt-doped magnesium aluminate spinel (Co:MgAl 2 O 4 ) allow the generation of short nanosecond pulse with high peak power around the eye-safe wavelength of 1.5um,perfect for telemetry applications. The absorption spectrum of Co 2+ -doped MgAl 2 O 4  exhibited a broad absorption band in the wavelength range of 1200–1600 nm, which indicated that Co 2+  ions substituted for the tetrahedrally coordinated Mg 2+  ions in the MgAl 2 O 4  lattice. Passive Q-switching of solid-state lasers with solid-state saturable absorbers is a very attractive Q-switching technique because it allows to develop compact and low cost laser sources of nano and sub nanosecond pulses far various applications Co spinel——saturable absorbers for the passive Q-switching of solid-state lasers operating at eye-safe wavelength of 1.5 μm Lasers emitting at 1.5µm are of great interest for several industrial applications. This interest is, first of all, due to eye-safety of 1.5-µm radiation. Oth

Co spinel  Q-Switch crystal Co spinel——saturable absorbers for the passive Q-switching of solid-state lasers operating at eye-safe wavelength of 1.5 μm Cobalt-doped magnesium aluminate spinel (Co:MgAl 2 O 4 ) allow the generation of short nanosecond pulse with high peak power around the eye-safe wavelength of 1.5um,perfect for telemetry applications. The absorption spectrum of Co 2+ -doped MgAl 2 O 4  exhibited a broad absorption band in the wavelength range of 1200–1600 nm, which indicated that Co 2+  ions substituted for the tetrahedrally coordinated Mg 2+  ions in the MgAl 2 O 4  lattice. Passive Q-switching of solid-state lasers with solid-state saturable absorbers is a very attractive Q-switching technique because it allows to develop compact and low cost laser sources of nano and sub nanosecond pulses far various applications Lasers emitting at 1.5µm are of great interest for several industrial applications. This interest is, first of all, due to eye-safety of 1.5-µm radiation. Ot

Er YAG laser Crystal—50% Erbium doped in YAG which can stimulate 2940nm laser used in medical and dentistry Erbium doped Yttrium Aluminum Garnet (Er:Y3Al5O12 or Er:YAG) combine various output wavelength with the superior thermal and optical properties of YAG. It is an excellent laser crystal which lasers at 2.94μm. This wavelength is the most readily absorbed into water and hydroxylapatite of all existing wavelengths and is considered a highly surface cutting laser. It is a well known material for medical applications. The emission wavelength of Er:YAG with doping concentration of 50% is 2940nm, which is at the position of water absorption peak and can be strongly absorbed by water molecules. Therefore, it is widely used in the field of plastic surgery and dentistry. At present, the projects we have participated in include laser blood collection instrument, which adopts the structure of both sides of Er:yag rods coated and xenon lamp end pumped.the Er-YAG laser wavelength is an excelle

Er,Yb:glass (Er glass) Er 3+  emission transition occurs within this wavelength range corresponding to the  4 I 13/2  → 4 I 15/2  . However, Er 3+ absorption itself is too weak to allow direct pumping and so, energy transfers are required. The most efficient ones are given by Yb 3+  ions under absorption from the  2 F 7/2  →  2 F 5/2  transition, followed by energy transfer to the  4 I 11/2  Er 3+  level and fast nonradiative transition to the Er 3+    4 I 13/2  level which emits the expected fluorescence.Er,Yb:glass laser with radiation output at the wavelength of 1540 nm does not require the addition of additional components. Er 3+ /Yb 3+  co-doped phosphate glass — as the 1540nm eye-safe radiation sources pumped by LD which can emit eye-safe 1540nm laser radiation directly used in laser ranging finder and telecommunication communication As an eye-safe wavelength laser, 1540um ,Er 3+ /Yb 3+  co-doped phosphate glass lasers have attracted much attention for their compactness and low cos

eye-safe laser(Er Glass Laser) 1535 solid-state eye-safe laser—Ultra compact eye-safe laser for ranging finder The wavelength of 1535nm is just in the position of the human eye and the atmospheric window, so it has been widely concerned in the fields of laser ranging and electronic communication. Er,Yb:glass lasers are most commonly used for laser rangefinders with a low pulse repetition rate (less than 10 Hz). Our eye-safe laser have already used in ranging finder and its ranging range is 3-5km with high stability, which applied in Gun aiming and UAV pod. Lasers with emission wavelengths longer than 1.4 μm are often called “eye-safe”, because light in that wavelength range is strongly absorbed in the eye’s cornea and lens and therefore cannot reach the significantly more sensitive retina. Obviously, the quality “eye-safe” depends not only on the emission wavelength, but also on the power level and the optical intensity which can reach the eye. Eye-safe lasers are particularly importan

er yag rod  Er YAG laser Crystal—50% Erbium doped in YAG which can stimulate 2940nm laser used in medical and dentistry The emission wavelength of Er:YAG with doping concentration of 50% is 2940nm, which is at the position of water absorption peak and can be strongly absorbed by water molecules. Therefore, it is widely used in the field of plastic surgery and dentistry. At present, the projects we have participated in include laser blood collection instrument, which adopts the structure of both sides of Er:yag rods coated and xenon lamp end pumped.the Er-YAG laser wavelength is an excellent choice for improvement of a variety of skin conditions and features of aging, including dyschromia, actinic photodamage, solar elastosis, acne and traumatic scarring, fine lines and mild to moderate rhytidosis, coarse skin texture, and skin laxity. Erbium doped Yttrium Aluminum Garnet (Er:Y3Al5O12 or Er:YAG) combine various output wavelength with the superior thermal and optical properties of YAG. I

Er Cr Yb Glass(1535nm Laser glass) Erbium Glass doped with Er 3+ , Yb 3+  and Cr 3+ , Erbium doped glass laser provides a useful coherent source in the spectral range near 1.5 μm, which is relatively safe for the human eye and is convenient in many applications, such as lidar and range measurements, fiber-optic communication, and laser surgery. In spite of the considerable progress in the development of InGaAs laser diode pump sources, Xe flashlamp will continue to be used as pump sources of Er:glass lasers because of their high reliability and low cost, and also the simplicity of design of such systems. Since about half the flashlamp radiation energy is emitted in the visible and near infrared (IR) ranges, a second sensitizer Cr 3+  is introduced into Yb-Er laser glasses to utilize this energy.

ZGP Nonlinear Crystal ZnGeP 2 （Zinc germanium phosphide）crystal has many good properties and is an mid-IR nonlinear crystal. The nonlinear susceptibility of ZnGeP 2  (ZGP) crystal is approximately 160 times large (d36~75 pm/V) as KDP,.ZGP shows good optical transparency over the 0.74–12 mm and relatively high laser damage threshold, and is therefore well suited for producing near infrared tunable laser. ZGP is a very hopeful material for mid-infrared devices such as SHG, SFG, OPO, and OPG/OPA.

Co Spinel Q-Switch Crystal Co spinel——saturable absorbers for the passive Q-switching of solid-state lasers operating at eye-safe wavelength of 1.5 μm Lasers emitting at 1.5µm are of great interest for several industrial applications. This interest is, first of all, due to eye-safety of 1.5-µm radiation. Other advantages of this wavelength are high transparency in atmosphere and fused-silica wave guides and availability of sensitive room temperature light detectors(Ge and InGaAs photo diodes).All this makes 1.5µm lasers very attractive for applications in range-finder, environmental sensing, telecommunications, surgery,etc. Co：Spinel absorption peak is close to 1520nm,which is most used in eye-safe laser. The absorption cross-section at 1520nm is 3.5×10 -19 cm 2  and at 1331 is 2.8×10 -19 cm 2 ,it has reported as Q-switch crystal for Er,Yb Glass and Nd:GYSGG,Nd:YALO 3.

LiNbO3 Crystal LiNbO 3  crystal has been widely used in optical waveguide and optical communication technology because of its excellent electro-optical properties. It is an ideal substrate material for many integrated optoelectronic devices. Because of the large electro-optic coefficient of LiNbO 3 , the half-wave voltage is low. The electro-optic effect of LiNbO 3  crystal is usually used to modulate the optical signal. Electro-optic modulation is divided into longitudinal and transverse, and LiNbO 3  is mainly used in transverse modulation. It has been widely used in medium and low power solid-state lasers.
